Color: black tube wall with sky blue anti-rolling plastic spiral reinforcement
Material: The pipe wall is made of EPDM/PP coated polyester fiber cloth, and the reinforcement is made of anti-rolling hard plastic spiral
Temperature resistance: + 200°C
Structural characteristics: Reinforcing ribs are resistant to rolling, and have good resilience characteristics; light weight, softness, excellent bending performance; high tensile strength and tear resistance, strong and durable.
Application: Automobile exhaust extraction system. When 50% fresh air is involved, the temperature resistance can reach 200 degrees.
| Part Number | Internal Diameter | External Diameter | Weight | Bending Radius | Vacuum | Coil Length |
| mm | mm | g/m | mm | bar | m | |
| 950-051-15 | 51 | 64 | 400 | 55 | 0.312 | 10/15 |
| 950-063-15 | 63 | 79 | 410 | 60 | 0.267 | 10/15 |
| 950-076-15 | 76 | 96 | 480 | 76 | 0.235 | 10/15 |
| 950-080-15 | 80 | 100 | 510 | 80 | 0.225 | 10/15 |
| 950-090-15 | 90 | 110 | 580 | 90' | 0.193 | 10/15 |
| 950-102-15 | 102 | 122 | 640 | 100 | 0.176 | 10/15 |
| 950-110-15 | 110 | 130 | 710 | 110 | 0.152 | 10/15 |
| 950-120-15 | 120 | 140 | 780 | 120 | 0.118 | 10/15 |
| 950-127-15 | 127 | 147 | 0.81 | 127 | 0.097 | 10/15 |
| 950-152-15 | 152 | 172 | 0.93 | 150 | 0.049 | 10/15 |
