color: White
Temperature range:-10°C/ + 80°C
Structural characteristics: PP polypropylene material (PVC polyvinyl chloride material is available for purchase) conveying pipe, which can be used in oily smoke environment, the length can be adjusted to 1.5 times, the caliber can be adjusted, and the temperature can be 80 ℃. Application: air cooler, air conditioner, exhaust, ventilation and dust collection, powder transportation, electrical wiring.
*A black product is available
| Part Number | Internal Diameter | External Diameter | Weight | Bending Radius | Coil Length |
| mm | mm | g/m | mm | m | |
| 501-050-10 | 50.0.±0.8 | 59.0±1.0 | 470±2% | 120 | 5/10 |
| 501-065-10 | 65.0±0.8 | 72.0±1.0 | 600±2% | 145 | 5/10 |
| 501-075-10 | 75.0±0.8 | 82.0±1.0 | 640±2% | 165 | 5/10 |
| 501-100-10 | 100.0±0.8 | 107.0±1.0 | 850±2% | 220 | 5/10 |
| 501-125-10 | 125.0±0.8 | 132.0±1.0 | 1070±2% | 325 | 5/10 |
| 501-150-10 | 150.0±1.5 | 157.0±1.5 | 1280±2% | 375 | 5/10 |
| 501-160-10 | 160.0±0.5 | 170.0±0.5 | 1356±2% | 398 | 5/10 |
| 501-200-10 | 200.0±2.0 | 211.0±2.0 | 2130±2% | 510 | 5/10 |
| 501-250-4 | 250.0±2.5 | 261.0±2.5 | 2660±2% | 680 | 4/10 |
